Product model

XCX-6070

Suitable for proccessing wire material

Multi strand copper wire,coaxial cable, sheathed wire,etc.

Memory storage function

100 programs

Display

7-inch color LCD touch screen display

Drive mode

12 feeding wheels drive

Blade material

Imported high speed steel

Wire diameter

6.0-70.0mm²

Feeding catheter

ø≤20mm

Cutting and peeling range

0-100m

Peeling length of fore-end/back-end

Fore-end:0-300mm,Back-end:0-150mm

Peeling speed

1500-2500 pcs/h

Cutting tolerance

±0.002mm*L

Peeling minimum length

≥50mm

Power consumption

800W

Power supply

AC 110V/220V 50/60HZ

Dimension

700*640*480mm

Weight

80kg
